Video Input Backglass Switchboard for Legends Pinball

Video Input Backglass Switchboard for Legends Pinball

Regular price $49.99 Promotion


Through the AtGames Open and Connected Pinball (OCP) initiative, you can connect your pinball engine-enabled external PC to the Legends Pinball, utilizing its large, dual-screen display and arcade controls. The Video Input Backglass Switch, or VIBS, is used to connect the PC to the Legends Pinball’s backglass display.

For setup instructions, please refer to the full PDF manual at: http://legendsultimate.atgames.net/arcade/assets/VIBS_InstructionManual.pdf

For a video highlighting VIBS installation, please refer to the following link on the AtGamesGaming YouTube channel: https://www.youtube.com/watch?v=EOfz7KOZvtc

Welcome message for new VIBS owners:
https://legendsultimate.atgames.net/arcade/assets/AtGamesVIBSforLegendsPinballOwnersIntroductoryOverview.pdf

Requirements

  • External pinball engine-enabled external PC.
  • NOTE: Steps for installation and configuration of the pinball engine/software on your PC and PC specifications are outside the scope of this project.
  • Two display outputs from your PC ending in HDMI cables used for connecting to the Legends Pinball machine.
  • VIBS for the AtGames Legends Pinball.
  • USB A  to USB A (2.0 or 3.0) cable used to connect your PC to the Legends Pinball machine.
  • Legends Pinball OCP is expecting two HDMI cables as input for feeding the dual displays.

NOTE: This product was not designed for the average user. Instead, it was created for a more technical DIY (Do It Yourself) user. The expectation is that the user of this product is experienced in modding and is prepared for and aware of the risks in the handling of sensitive electronic components. Additionally, some users have reported problems with using AMD Radeon graphics cards when connected to this product. Some potential workarounds have been posted on Wagner's Tech Talk at this link: http://wagnerstechtalk.com/alp/#VIBS_Troubleshooting. Finally, AtGames can only provide warranty coverage for this product (https://www.atgames.net/arcades/warranty/). For technical questions or other operational issues, please utilize The Official AtGames Pinball Fan Page on Facebook (https://www.facebook.com/groups/166745557972535).
